1756-PSCA2 - 24VDC Redundant Power Supply - Industrial Control Rugged Hot-Swap Module
| MOQ: | 1 |
| Price: | Negotiable |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
industrial allen bradley module
,industrial allen bradley plc
,Standard allen bradley module
| Attribute | Value |
|---|---|
| Signal Delay | 35 or 45 milliseconds |
| Analog Inputs | Thermocouple |
| Hardware Type | I/O Chassis |
| Voltage Range | 85-132 Volts AC |
| Phase | Three-Phase |
| Wire Type | Copper |
| Number Of Inputs | 8 Differential Inputs |
| Operating Temperature | -20 to 60 degrees Celsius |
The Allen-Bradley 1756-PSCA2 Power Supply Control Adapter is a critical monitoring module for Rockwell Automation's ControlLogix® systems, enabling advanced diagnostics and redundancy management in mission-critical power architectures. Designed to interface with 1756-Px series power supplies, it provides real-time voltage, current, and thermal telemetry via the chassis backplane.
Housed in a single-slot module with ruggedized zinc-alloy construction, it withstands industrial vibrations (5g IEC 60068-2-6) and operates from -40 °C to +70°C. Key features include dual-mode redundancy control (active/standby coordination), predictive failure alerts, and hot-swap synchronization to ensure zero downtime during maintenance.
- Input Monitoring: 0.1% accuracy for ±50mV DC voltage / ±10mA current sensing
- Redundancy Control: Manages up to 4 parallel power supplies
- Compatibility: Interfaces with 1756-PA72, PB75, PBXT series PSUs
- Communication: 57.6 kbps serial link via 1756 backplane
- Sampling Rate: 10ms update cycle for all parameters
- Isolation: 1500V AC input-to-backplane protection
- LED Indicators: PSU status (green/amber/red) + load balancing alerts
- Environmental: UL Type 12/IP52, ATEX Cat 3 Zone 2 compliant
- Safety Certifications: UL 61010-1, IEC 61508 SIL 2
- Energy Substations: Dual-fed PSU monitoring for SCADA control cabinets
- Automotive Production: Redundant power management in robotic paint shops
- Pharmaceutical: Cleanroom batch process UPS synchronization
- Chemical Plants: SIL 2-compliant reactor control power backups
- Water Treatment: Flood-prone pump station power redundancy
- Data Centers: Industrial-grade UPS health monitoring
- Mining: Conveyor motor control center power diagnostics
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Series/Platform | ControlLogix® Redundancy System |
| Module Type | Power Supply Monitor |
| Part Number | 1756-PSCA2 |
| Primary Function | Monitors redundant power supplies in ControlLogix chassis; manages power fault responses |
| Compatible Chassis | 1756-A4, A7, A10, A13, A17 (Redundancy-enabled chassis) |
| Power Supply Compatibility | 1756-PBxx, 1756-PCxx, 1756-PHxx series (Monitors up to 4 supplies per chassis) |
| Voltage Monitoring Range | 5V DC backplane: ±5% tolerance 24V DC user power: ±15% tolerance |
| Supply Margin Monitoring | Detects voltage degradation before failure (configurable thresholds) |
| Communication Interface | ControlNet (CNET) via 1756-CNx module Serial port for local diagnostics |
