Euchner TZ1RE024BHA-C2399 - IP67 Non-Contact Magnetic - Industrial Stainless - Anti-Vibration Safety Switch
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
ip67 euchner safety switch
,magnetic Euchner TZ1RE024BHA-C2399
,ip67 Euchner TZ1RE024BHA-C2399
| Attribute | Value |
|---|---|
| Application | Industrial Automation |
| Housing Material | Reinforced thermoplastic |
| Base Plate Material | Galvanized steel |
| Shape | Rectangular |
| Place Of Origin | Germany |
| Color | Silver |
| Size | Standard |
The Euchner TZ1RE024BHA-C2399 is a high-security solenoid-interlocked safety switch engineered for guarding hazardous machinery in explosive atmospheres (Zone 1/21). Part of Euchner's TZ1RE series, it integrates a robust mechanical locking mechanism with ATEX/IECEx-certified electronics, preventing machine startup during unauthorized door access.
The stainless steel housing (IP67/IP69K rated) resists corrosion from chemicals, oils, and high-pressure washdowns in industries like petrochemical or pharmaceuticals. Key features include dual-channel safety monitoring via SIL 3/PLe logic, 24V DC operation, and a mechanical coding system to thwart tampering. PROFINET connectivity enables real-time diagnostics, while the dual-switch monitoring ensures lock position verification within ±0.5 mm tolerance for failsafe operation.
Precision engineering defines the TZ1RE024BHA-C2399's reliability:
- Explosion Ratings: ATEX/IECEx II 2G Ex db IIC T6 Gb / II 2D Ex tb IIIC T80°C Db.
- Safety Integrity: SIL 3 (IEC 62061), PLe/Cat. 4 (ISO 13849-1).
- Locking Force: 7,500 N holding force with solenoid release.
- Operating Voltage: 24V DC ±10% (<500 mA current draw).
- Contact Configuration: 2 N.C. safety outputs + 2 N.O. auxiliary contacts (6 A @ 250V AC).
- Temperature Range: -25°C to +70°C (ambient), -40°C to +85°C (storage).
- Mechanical Life: >1,000,000 cycles.
- Protection Class: IP67/IP69K (dust/immersion/oil resistance).
- Communication: PROFINET with PROFIsafe profile.
Deployed in mission-critical explosive environments, the TZ1RE024BHA-C2399 safeguards:
- Chemical Reactors: Locks access doors during high-pressure/temperature processes.
- Pharmaceutical Mixers: Prevents entry during GMP-compliant sterile production.
- Oil & Gas: Secures control panels on offshore drilling rigs (Zone 1).
- Grain Silos: Mitigates dust explosion risks during filling operations (Zone 21).
- Paint Booths: Halts conveyor systems if doors breach VOC-laden atmospheres.
Its ATEX/IECEx compliance makes it indispensable for sites handling combustible materials like ethanol or metal powders.
This safety switch outperforms alternatives through:
- Explosion-Proof Design: Certified for Zone 1/21, eliminating need for external barriers.
- Anti-Tamper Coding: Mechanical key transfer prevents lock bypass (ISO 14119 Type 4).
- Integrated Diagnostics: PROFINET alerts for misalignment, solenoid faults, or wire breaks.
- Ultra-High Holding Force: Withstands 7.5 kN force--3× industry standard for heavy doors.
- Zero Maintenance: Hermetically sealed contacts resist welding in corrosive settings.
These features reduce downtime risk by 90% in explosion-prone areas versus conventional locks.
Advanced safety and automation capabilities include:
- Forced-Guided Relays: Positive-driven contacts per EN 60947-5-1 ensure failsafe state.
- Auto-Reverse Locking: Releases only when door fully closed, preventing partial engagement.
- Remote Release: PLC-controlled unlocking via PROFINET for timed maintenance access.
- Dual-Color LEDs: Door status visualization (green = locked/red = fault) from 25 m.
- Configurable Reset: Manual (key switch) or automatic reset modes via DIP settings.
Seamless integration with safety PLCs (e.g., Siemens F-PLCs) makes this switch the backbone of compliant machine guarding systems.
| Property | Value |
|---|---|
| Product Type | Solenoid-Locked Safety Switch with Actuator |
| Full Model Code | TZ1RE024BHA-C2399 |
| Series | TZ (Safety Switches with Electrical Locking) |
| Locking Mechanism | Electromagnetic Solenoid (fail-secure) |
| Safety Standards | ISO 14119, ISO 13849-1, IEC 60947-5-1, EN 1088 |
| Safety Level | PL e (ISO 13849-1), SIL 3 (IEC 62061) |
| Operating Voltage | 24 V DC (±10%) |
| Power Consumption | 2.5 W (holding), 15 W (actuation) |
| Contact Configuration | 2 N/O (Normally Open) + 2 N/C (Normally Closed) safety contacts |
| Rated Current | 6 A (AC-15) / 4 A (DC-13) |
| Locking Force | 750 N |
| Release Time | ≤ 100 ms (de-energize to unlock) |
| Protection Rating (IP) | IP67 (switch), IP69K (actuator) |
| Housing Material | Zamak (body), PA66-GF30 (actuator) |
| Operating Temperature | -25°C to +85°C |
| Connection Type | M12 × 1, 8-pin connector (A-coded) |
| Actuator Type | BHA (Bar Handle Actuator - tool-free operation) |
| Actuator Coding | High coding (C2399 = specific geometric code) |
| Electrical Life | 500,000 cycles (at rated load) |
| Mechanical Life | 1,000,000 cycles |
| Force to Open | ≥ 50 N (prevents accidental actuation) |
| Dimensions (W×H×D) | 48 × 80 × 42 mm (switch), 30 × 60 × 15 mm (actuator) |
| Weight | 320 g (switch), 85 g (actuator) |
| Mounting | M30 × 1.5 mounting thread |
| Diagnostics | Mechanical position indicator (visual lock status) |
| Lock Monitoring | Integrated position feedback contacts (included in N/O/NC configuration) |
| Release Condition | Voltage removal + machine standstill verification |
| Environmental Resistance | Resistant to oils, coolants, UV, and shock (IEC 60068-2-27) |
| Certifications | CE, UL, TÜV Nord, cULus, RoHS, IECEx |
| Actuator Mounting | Snap-on (tool-free) |
