1004306 - IP67 Quick-Connect - Industrial Auto Stainless High-Current - Circular Connector
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
industrial Phoenix Contact Housing
,industrial Phoenix Contact plc
,ip67 Phoenix Contact Housing
| Attribute | Value |
|---|---|
| Ip Rating | IP20 or IP67 |
| Housing Type | DIN rail housing |
| Dimensions | Varies depending on model |
| Printing | Laser printer |
| Mounting Type | DIN rail or panel mount |
| Product | Tools & Accessories |
| Wire Gauge Max | 12 AWG |
| Drive And Function | monostable |
The Phoenix Contact 1004306 is a high-performance terminal block designed to ensure secure electrical connectivity in industrial automation systems. Part of Phoenix Contact's CLIPLINE series, this component provides reliable power and signal transmission in demanding environments such as manufacturing plants, energy distribution systems, and transportation infrastructure.
Its modular design enables DIN rail mounting (EN 60715), facilitating seamless integration into control cabinets and high-density installations. The terminal block features a durable polyamide housing with flame-retardant properties (UL94 V-0 rated), ensuring resistance to mechanical stress, heat, and chemical exposure.
Engineered for versatility, the 1004306 supports both single- and multi-wire connections, accommodating a broad range of conductor types. The transparent housing allows quick visual inspection of wire seating, minimizing maintenance downtime. Compliance with IEC 60947 and UL 1059 standards guarantees global applicability and safety.
- Rated Voltage: 300 V AC/DC
- Current Rating: 17.5 A (continuous), suitable for high-power applications
- Wire Cross-Section: 0.08-6 mm² (fine-stranded) / 0.08-4 mm² (solid conductors)
- Temperature Range: -60°C to +100°C (operational), ensuring performance in extreme conditions
- Contact Material: Tin-plated copper alloy for corrosion resistance and optimal conductivity
- Insulation Resistance: >1000 MΩ (at 500 V DC), minimizing leakage risks
- Mounting: Compatible with 35 mm DIN rails for tool-free installation
- Certifications: UL 508, CE, cULus, and RoHS/REACH compliance
- Motor Control Systems: Connects motor starters, VFDs (Variable Frequency Drives), and overload relays in manufacturing and robotics
- Power Distribution: Routes high-current signals in switchgear and energy management systems
- PLC and Controller Wiring: Links sensors, actuators, and I/O modules to automation controllers
- Renewable Energy: Integrates into solar inverters and wind turbine control units
- Transportation Infrastructure: Deployed in railway signaling and electric vehicle charging stations
- Tool-Free Installation: Push-in spring-cage technology enables fast, secure wire connections without screws or tools
- High Surge Capacity: Handles up to 17.5 A, critical for motor starters and inductive loads
- Modular Scalability: Interlocking side walls allow easy expansion by connecting multiple blocks
- Transparent Housing: Simplifies visual inspection of connections, reducing diagnostic time
- Eco-Friendly Compliance: Halogen-free materials and RoHS compliance align with sustainability goals
- Multi-Wire Support: Accommodates up to four conductors per terminal, optimizing space in control panels
- Test Points: Integrated sockets enable voltage/current measurements without disconnecting wires
- Polarized Design: Prevents mismating in multi-pole configurations, ensuring error-free installation
- Vibration Resistance: Spring-loaded contacts maintain stability in high-vibration environments
- Dual-Level Labeling: Write-on tabs provide clear circuit identification and documentation compliance
| Property | Specification |
|---|---|
| Product Type | Electromechanical Relay Module |
| Model Number | 1757022 |
| Series | REL-MR-24DC/21-21 |
| Rated Voltage (Coil) | 24 V DC (±20%) |
| Contact Configuration | 2 NO (Normally Open) Contacts |
| Switching Capacity | - AC: 250 V, 8 A (resistive load) - DC: 24 V, 8 A (resistive load) |
| Max. Switching Current | 8 A |
| Max. Switching Voltage | 250 V AC / 24 V DC |
| Contact Material | Silver Alloy (AgSnO₂) |
| Electrical Life | 100,000 cycles (at rated load) |
| Mechanical Life | 10,000,000 cycles |
| Response Time | ≤15 ms (operate time) / ≤5 ms (release time) |
| Insulation Voltage | 4 kV (between coil and contacts) |
| Power Consumption | ≤1.2 W (at 24 V DC) |
| Mounting Type | DIN Rail (TS35) |
| Connection Type | Screw Clamp |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Protection Class | IP20 (front) / IP00 (terminals) |
| Safety Standards | EN 61810-1, UL 508, CSA C22.2 No. 14, RoHS, REACH |
| Dimensions (W×H×D) | 17.5 mm × 99 mm × 114 mm |
| Weight | ~130 g |
| Certifications | CE, UL Listed, cULus, EAC (Eurasian Compliance) |
| Applications | PLC systems, control cabinets, machinery, HVAC, and power distribution systems |
