790462 Phoenix Contact Housing Industrial High Current High Performance Rectangular Connector
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
790462 Phoenix Contact Housing
,High Performance 790462 Phoenix Contact
,Rectangular 790462 Phoenix Contact
| Attribute | Value |
|---|---|
| Components | Silicone-free |
| Screw Type | M3 |
| PCB Thickness | 1.4 mm ... 1.8 mm |
| Maximum Stripping Length | 12 mm |
| Screw Thread | M3 |
| IP Rating | IP20 |
| Insulating Material | PA |
| Coating | Tin-plated (galvanic) |
The Phoenix Contact 790462 is a high-performance terminal block designed for secure electrical connectivity in industrial control and automation systems. Part of Phoenix Contact's CLIPLINE series, this component ensures reliable power and signal transmission in demanding environments such as manufacturing plants, energy distribution systems, and transportation infrastructure.
Its modular design allows for DIN rail mounting (EN 60715), enabling efficient integration into control cabinets and high-density installations. The terminal block features a durable polyamide housing with flame-retardant properties (UL94 V-0 rated), ensuring resistance to mechanical stress, heat, and chemical exposure.
Engineered for versatility, the 790462 supports both single- and multi-wire connections, accommodating a wide range of conductor types. The transparent housing design facilitates quick visual inspection of wire seating, reducing maintenance downtime. Compliance with international standards like IEC 60947 and UL 1059 guarantees global applicability and safety.
- Rated Voltage: 300 V AC/DC
- Current Rating: 17.5 A (continuous), suitable for high-power applications
- Wire Cross-Section: 0.08-6 mm² (fine-stranded) / 0.08-4 mm² (solid conductors)
- Temperature Range: -60°C to +100°C (operational), ensuring performance in extreme conditions
- Contact Material: Tin-plated copper alloy for corrosion resistance and optimal conductivity
- Insulation Resistance: >1000 MΩ (at 500 V DC), minimizing leakage risks
- Mounting: Compatible with 35 mm DIN rails for tool-free, snap-on installation
- Certifications: UL 508, CE, cULus, and RoHS/REACH compliance
- Motor Control Systems: Connects motor starters, VFDs (Variable Frequency Drives), and overload relays in manufacturing and robotics
- Power Distribution Panels: Routes high-current signals in switchgear and energy management systems
- PLC and Controller Wiring: Links sensors, actuators, and I/O modules to automation controllers
- Renewable Energy Installations: Integrates into solar inverters and wind turbine control units
- Transportation Infrastructure: Used in railway signaling and electric vehicle charging stations
| Property | Specification |
|---|---|
| Product Type | PCB Terminal Block (Plug-in Connector) |
| Model Number | 790462 |
| Series | COMBICON MSTB |
| Pitch | 5.08 mm |
| Number of Poles | 6 |
| Rated Voltage | 300 V AC/DC |
| Rated Current | 12 A |
| Wire Size | 0.2-4 mm² (solid/flexible) / 0.2-6 mm² (fine-stranded with ferrule) |
| Contact Material | Brass, tin-plated |
| Housing Material | Polyamide (PA66), UL 94 V-0 flame-retardant |
| Clamping Type | Push-in CAGE CLAMP® (screwless) |
| Torque | Not required (tool-free connection) |
| Operating Temperature | -40°C to +105°C |
| Storage Temperature | -40°C to +120°C |
| Isolation Voltage | 4 kV AC (between poles) |
| Protection Class | IP20 (when mounted on PCB) |
| Safety Standards | UL 1059, CSA C22.2 No. 158, EN 60947-7-1, RoHS, REACH |
| Certifications | UL Recognized, CSA, CE, EAC |
| Mounting | PCB-mounted (THT, through-hole technology) |
| Connection Type | Tool-free wire insertion (Push-in CAGE CLAMP®) |
| Dimensions (L×W×H) | 30.5 mm × 5.08 mm × 15.5 mm (per pole) |
| Weight | ~7.5 g (per pole) |
| Applications | Power distribution, control boards, PLC systems, and industrial electronics |
