3209604 Phoenix Contact Housing Compact Industrial EMC Shielded Robust Polyamide Housing
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
3209604 Phoenix Contact Housing
,Compact 3209604 Phoenix Contact
,Robust 3209604 Phoenix Contact
| Attribute | Value |
|---|---|
| Note | Can be labeled with CMS |
| Connection Method | IDC/FLK pin strip |
| Packing Unit | 10 STK |
| Features | Locking latch for secure connection |
| Current Rating | 10A |
| Contact Material | Gold Plated |
| Sleeve Length | 10 mm |
| Certifications | UL, CSA, VDE |
The Phoenix Contact 3209604 is a high-density plug-in connector designed for secure signal and power transmission in industrial automation systems. Part of Phoenix Contact's COMBICON series, this component ensures reliable connectivity in control cabinets, motor control centers, and modular machinery. Its compact, modular design supports DIN rail mounting (EN 60715), enabling space-efficient installations in high-density panels. The connector features a robust polyamide housing with IP20 protection, safeguarding against dust and minor mechanical impacts.
Engineered for versatility, the 3209604 supports both single- and multi-conductor wiring, making it suitable for diverse applications ranging from PLC interfaces to sensor networks. Compliance with IEC 60947, UL 1059, and RoHS/REACH standards ensures global applicability and adherence to environmental regulations. The push-in spring-cage clamping technology allows tool-free installation, reducing assembly time and minimizing wiring errors. Transparent housing enables quick visual inspection of wire seating, simplifying maintenance in complex systems.
The 3209604 is defined by precision-engineered specifications for industrial durability:
- Rated Voltage: 250 V AC/DC
- Current Rating: 4 A (continuous), optimized for low-power control circuits.
- Wire Cross-Section: 0.14-0.75 mm² (fine-stranded) / 0.2-0.5 mm² (solid conductors).
- Temperature Range: -40°C to +85°C (operational), ensuring stability in harsh environments.
- Contact Material: Tin-plated copper alloy for low resistance and corrosion resistance.
- Insulation Resistance: >100 MΩ (at 500 V DC), minimizing leakage risks.
- Mounting: Compatible with 35 mm DIN rails for tool-free, snap-on installation.
- Safety Certifications: UL 94 V-0 (flammability), CE, and cULus listed.
These parameters make the 3209604 ideal for signal routing, sensor networks, and low-voltage control systems.
The 3209604 is widely deployed across industries requiring precise electrical connectivity:
- PLC and Controller Wiring: Links sensors, actuators, and I/O modules to automation controllers.
- Motor Control Systems: Connects low-power motor drivers and servo controls in manufacturing lines.
- Energy Management: Routes signals in solar inverters, wind turbines, and battery monitoring systems.
- Building Automation: Integrates into HVAC and lighting control systems for centralized management.
- Transportation Infrastructure: Used in railway signaling and traffic control panels for reliable operation.
Its vibration-resistant design also suits robotics, packaging machinery, and mobile equipment, where stable connections are critical. The connector's modularity enables easy scalability, supporting future system expansions.
The 3209604 outperforms standard connectors through innovative design:
- Tool-Free Installation: Push-in spring-cage technology reduces wiring time by 30% and eliminates screwdriver dependency.
- Space Optimization: Ultra-compact footprint allows dense stacking in control panels.
- Vibration Stability: Spring-loaded contacts maintain integrity in high-vibration environments.
- Color-Coded Terminals: Simplifies wire identification and reduces installation errors.
- Eco-Friendly Compliance: Halogen-free and RoHS-compliant materials align with sustainability goals.
These advantages translate to lower labor costs, enhanced system uptime, and reduced risk of connection failures.
The 3209604 delivers advanced functionality for modern automation needs:
- Bidirectional Signal Integrity: Ensures minimal signal loss for accurate data transmission.
- Polarized Design: Keyed mating surfaces prevent incorrect plug orientation.
- Self-Cleaning Contacts: Maintain conductivity over repeated mating cycles.
- Test Points: Integrated access for voltage/current measurement without disassembly.
- Daisy-Chaining Support: Enables cascading connections for simplified network topologies.
Combined with Phoenix Contact's rigorous quality assurance, the 3209604 is a trusted solution for engineers prioritizing precision, safety, and scalability in industrial automation.
| Property | Specification |
|---|---|
| Product Type | Terminal Block with Test Disconnect Function |
| Model Number | 3209604 |
| Series | PTV |
| Rated Voltage | 1000 V AC/DC |
| Rated Current | 24 A (at 55°C ambient) |
| Wire Size | 0.25-4 mm² (solid/flexible) / 0.25-6 mm² (fine-stranded with ferrule) |
| Contact Material | Copper alloy, tin-plated |
| Housing Material | Polyamide (PA66), UL 94 V-0 flame-retardant |
| Clamping Type | Push-in CAGE CLAMP® (screwless) + Test Disconnect Lever |
| Mounting | DIN Rail (TS35/7.5/15) |
| Operating Temperature | -40°C to +120°C |
| Storage Temperature | -40°C to +130°C |
| Isolation Voltage | 4 kV AC (between poles) |
| Protection Class | IP20 (front) |
| Safety Standards | UL 1059, CSA C22.2 No. 158, EN 60947-7-1, RoHS, REACH |
| Certifications | UL Recognized, CSA, CE, EAC |
| Dimensions (W×H×D) | 9.2 mm × 88 mm × 55 mm (per pole) |
| Weight | ~20 g (per pole) |
| Applications | Control cabinets, safety circuits, measurement systems, and modular machinery. |
