800886 - IP67 Quick-Lock - Industrial EMC Shielded High-Temp - Circular Connector

The Phoenix Contact 800886 is a high-performance surge protection module designed to safeguard sensitive industrial automation equipment from voltage spikes and transient overvoltages. Part of Phoenix Contact's TRABTECH series, this device ensures reliable protection for control systems, communication networks, and power supplies in harsh environments.

Its compact, DIN rail-mountable design (EN 60715) allows seamless integration into control cabinets, motor control centers, and switchgear panels. The module features a robust polycarbonate housing with IP20 protection, providing resistance to dust and mechanical impacts.

Engineered for universal compatibility, the 800886 supports a wide range of industrial applications, including PLCs, sensors, and communication interfaces. Compliance with IEC 61643-11, UL 1449, and RoHS/REACH standards ensures global safety and environmental compliance. Its visual status indicators (green/red LEDs) provide real-time monitoring of protection status, simplifying maintenance and fault detection.

The 800886 is defined by precision-engineered specifications for surge protection:

• Rated Voltage: 24 V DC (for control circuits) / 230 V AC (for power lines)
• Maximum Discharge Current (Imax): 20 kA (8/20 µs pulse), ensuring robust protection against lightning-induced surges
• Voltage Protection Level (Up): <1.5 kV (for 24 V DC systems), minimizing risk to sensitive electronics
• Response Time: <1 ns, providing near-instantaneous reaction to transient events
• Operating Temperature: -40°C to +80°C, suitable for extreme industrial environments
• Connection Type: Screw terminals for secure, vibration-resistant wiring (0.2-4 mm² conductor cross-section)
• Certifications: UL 1449 (Type 4), CE, and IEC 61643-11 (surge protective devices)

These parameters make the 800886 ideal for protecting low-voltage control systems and communication networks.

The 800886 is critical in safeguarding automation infrastructure across industries:

• PLC and Controller Protection: Shields I/O modules and control logic from voltage surges in manufacturing and robotics
• Sensor Networks: Protects analog/digital sensors in process automation (e.g., chemical plants, water treatment)
• Communication Lines: Secures RS-485, Ethernet, and fieldbus systems (PROFIBUS, CANopen) in industrial networks
• Renewable Energy Systems: Protects solar inverters and wind turbine controllers from lightning-induced surges
• Transportation Infrastructure: Used in railway signaling and traffic control systems to ensure uninterrupted operation

Its robust design also suits oil and gas facilities, where explosive atmospheres (ATEX compliance may vary) and electrical noise are prevalent.
