19200101540 - IP67 Quick-Lock - Industrial Stainless Rugged - Rectangular Connector

The HARTING 19200101540 is a high-performance single-pole power connector from the Han® 1A series, designed for demanding industrial automation and energy distribution applications. Built with a rugged polyamide (PA) housing, it offers IP65/67 protection against dust, water, vibration, and chemical exposure, ensuring reliability in harsh environments.

The connector features push-in termination technology for tool-free assembly, significantly reducing installation time. Rated for high-current transmission, it is ideal for motor connections, control cabinets, and renewable energy systems. Its compact design and modular compatibility with Han® 1A hybrid inserts enable space-efficient integration into machinery, electric vehicles, and smart grid infrastructure.

• Rated Voltage/Current: 630V AC, 41A (continuous)
• Contact Resistance: ≤1.5 mΩ (initial)
• Insulation Resistance: ≥5,000 MΩ (1,000V DC)
• Operating Temperature: -40°C to +120°C
• Protection Class: IP65/67 (mated), IP20 (unmated)
• Termination Type: Push-in technology for fast, tool-free wiring
• Certifications: UL, CSA, CE, RoHS

The 19200101540 is widely deployed in industrial motor control systems, providing robust connections for servo drives, frequency inverters, and robotic arms. In renewable energy, it ensures efficient power transmission in solar inverters and wind turbine generators.

Manufacturing facilities utilize it in CNC machines, conveyor systems, and assembly lines requiring high-current durability. Transportation sectors rely on it for rail traction systems and electric vehicle charging stations. Its IP67 rating makes it suitable for outdoor or washdown environments, such as food processing plants and chemical processing units.

• High-Current Capacity: Supports 41A for heavy-duty industrial loads
• Tool-Free Installation: Push-in termination reduces wiring time by 60%
• Modular Flexibility: Compatible with Han® 1A hybrid inserts for mixed power/signal configurations
• Rugged Construction: Vibration-resistant PA housing and gold-plated contacts ensure longevity under extreme conditions
• Global Compliance: Meets UL, CSA, and ATEX standards for hazardous area deployments
