09000005072 - Quick-Lock High-Reliability - Industrial Auto IP65 Stainless - Rectangular Connector
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
industrial Harting Connector Han
,Rectangular Harting Connector Han
,industrial Harting plc
| Attribute | Value |
|---|---|
| Pack Contents | With seal screw |
| Operating Temperature | -40°C to +125°C |
| Connector Type | Rectangular |
| Manufacturer | Harting |
| Type | Low construction |
| Limiting Temperature | -40 ... +125 °C |
| Approvals | DNV GL |
| Termination Style | Crimp |
The HARTING 09000005072 is a compact, high-performance single-pole power connector from the Han® 1A series, designed for industrial automation and power distribution applications. Featuring a rugged polyamide (PA) housing with IP65/67 protection, it withstands harsh environments exposed to dust, moisture, oils, and mechanical stress.
- Rated Voltage/Current: 630V AC, 41A (continuous)
- Contact Resistance: ≤1.5 mΩ (initial)
- Insulation Resistance: ≥5,000 MΩ (1,000V DC)
- Operating Temperature: -40°C to +120°C
- Housing Material: PA (UL94 V0 flame-retardant)
- Protection Class: IP65/67 (mated), IP20 (unmated)
- Termination Type: Push-in technology for fast, tool-free wiring
- Certifications: UL, CSA, CE, RoHS
- Contact Options: Solid or spring-loaded power contacts
The 09000005072 is widely used in industrial motor control systems, providing reliable power connections for servo drives, frequency inverters, and robotic arms. In renewable energy, it ensures efficient power transmission in solar inverters and wind turbine generators. Manufacturing facilities deploy it in CNC machines, conveyor belts, and assembly lines where high-current durability is critical.
- High-Current Capacity: Supports 41A for demanding industrial loads
- Tool-Free Installation: Push-in termination reduces wiring time by 60%
- Modular Flexibility: Compatible with Han® 1A hybrid inserts for mixed power/signal setups
- Robust Design: Vibration-resistant PA housing and gold-plated contacts ensure longevity
- Global Compliance: Meets UL, CSA, and ATEX standards for hazardous area deployments
| Attribute | Specification |
|---|---|
| Product Series | Han® Modular Industrial Connector |
| Model Number | 09000005072 |
| Type | Crimp Contact, Male (Pin) for Han® Modular Connectors |
| Material | Brass (Tin-Plated for Corrosion Resistance) |
| Current Rating | Up to 40 A (at 250 V AC) |
| Voltage Rating | 1,000 V AC/DC (Max) |
| Contact Resistance | ≤ 1.5 mΩ |
| Wire Size | 1.5 -6 mm² (AWG 16-10) |
| Temperature Range | -40 °C to +125°C (-40°F to +257°F) |
| IP Rating | IP65/IP67 (when fully mated with compatible housing) |
| Mounting Style | Crimp Termination (Requires Harting-Specific Crimping Tools) |
| Compliance Standards | IEC 61984, UL 1977, CSA 22.2, RoHS, REACH |
