MTS RHM0150MD601A11 - 150mm IP67 Non-Contact - Industrial Stainless - High-Accuracy Linear Sensor
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
ip67 MTS RHM0150MD601A11
,ip67 electronic circuit breaker
,industrial MTS RHM0150MD601A11
| Attribute | Value |
|---|---|
| Model | MTS-100 |
| Compatibility | Universal |
| Power Source | Battery |
| Battery Life | 10 hours |
| Wireless Technology | Bluetooth |
| Material | Plastic |
| Color | Black |
| Connectivity | Wireless |
The MTS RHM0150MD601A11 is a high-performance magnetostrictive linear position transducer engineered for critical industrial automation applications. Utilizing Temposonics® R-Series technology, it provides absolute position measurement across a 150mm stroke with ±0.02% FS accuracy without mechanical contact. The sensor features a laser-welded 316L stainless-steel housing (IP68/IP69K rated) capable of withstanding 500-bar pressure, extreme temperatures (-40°C to +125°C), and 100g shock loads. Integrated IO-Link connectivity (MD601 suffix) enables real-time diagnostics and plug-and-play integration with Industry 4.0 systems.
- Stroke Length: 150 mm (±75mm bidirectional measurement)
- Accuracy: ≤±0.02% full scale at 20°C (±0.05% over -40°C to +85°C)
- Output Signals: 4-20mA analog + IO-Link V1.1 (COM2/COM3)
- Resolution: 0.001 mm (16-bit internal processing)
- Non-Linearity: <±0.01% FS with dynamic compensation
- Response Time: <0.8 ms (analog) / <2 ms (digital)
- Pressure Rating: 500 bar static / 350 bar dynamic
- Housing: Corrosion-resistant 316L stainless steel (1.4404)
- Connection: 5-pin M12 connector (A-coded, 360° rotatable)
- EMC Immunity: EN 61000-6-2/4 (200 V/m RF)
- Vibration Resistance: 20g @ 10-2000 Hz (IEC 60068-2-6)
- Mechanical Life: >100 million cycles (non-contact principle)
- Hydraulic Presses: Real-time die-height control in 10,000-ton stamping operations (±0.05mm repeatability)
- Mobile Machinery: Boom cylinder positioning in Tier-4 construction equipment
- Steel Production: Continuous casting mold oscillation monitoring under 1300°C thermal radiation
- Offshore Systems: Subsea valve actuation at 3,000m depth (DNV-GL certified)
- Test Equipment: High-cycle fatigue testing with 500Hz sampling rates
- Robotics: Precision end-effector positioning in automotive body shops
- Barrier Penetration: Measures through 6mm non-ferrous materials
- Absolute Positioning: No homing required after power interruption
- Drift Immunity: ASIC thermal compensation (≤0.002% FS/°C)
- Predictive Maintenance: IO-Link monitors waveguide integrity & temperature trends
- Overload Protection: 150% stroke overtravel tolerance
- Zero Contact: Infinite mechanical lifespan vs. wear-prone potentiometers
Reduces calibration costs by 85% and eliminates unplanned downtime through embedded diagnostics.
