KEYENCE PZ-G52N Precision Photo Sensor | Industrial Automation, Reliable Sensing
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
Detail Information
Place of Origin
Japan
Brand Name
KEYENCE
Certification
3C
Model Number
PZ - G52N
Operating Temperature:
0°C To 50°C
Quality:
100% Original 100% Brand
Application:
Industrial Automation
Input Type:
Bidirectional Voltage Input
Number Of Pixels:
1280 × 1024 Pixels
Linearity:
±0.1 % Of F.S. (±28 µm ±1.10 Mil)*4
Measurement Range:
0.01mm To 100mm
Detecting Distance:
30 To 500 Mm 1.18
Highlight:
industrial keyence inspection system
,reliable KEYENCE PZ-G52N
,industrial KEYENCE PZ-G52N
Product Description
KEYENCE PZ-G52N Precision Photo Sensor | Industrial Automation, Reliable Sensing
Product Attributes
| Attribute | Value |
|---|---|
| Operating Temperature | 0°C to 50°C |
| Quality | 100% Original 100% Brand |
| Application | Industrial Automation |
| Input Type | Bidirectional voltage input |
| Number Of Pixels | 1280 × 1024 pixels |
| Linearity | ±0.1 % of F.S. (±28 µm ±1.10 Mil)*4 |
| Measurement Range | 0.01mm to 100mm |
| Detecting Distance | 30 to 500 mm 1.18 |
Product Description
Advanced Through-Type Photoelectric Sensing
KEYENCE PZ-G52N is an advanced through-type photoelectric sensor engineered for industrial automation. Utilizing a red LED light source, it ensures clear and stable detection. With a response time of 500 µs, it quickly reacts to object presence or absence, vital for high-speed production lines. Its collector-open output (max 30 V, 100 mA) provides flexible control, while protection circuits against reverse polarity, over-current, and surge absorbance safeguard reliability in harsh electrical conditions.
Robust and Reliable Construction
Built for durability, the PZ-G52N features an enclosure rating of IP67/IP69K, offering excellent dust and water resistance. Its rectangular shape allows easy installation in tight spaces. Constructed with high-quality materials, it withstands vibrations (10-55 Hz, 1.5 mm double amplitude) and shocks, ensuring long-term performance. The operating temperature range suits various industrial settings, making it a reliable choice for continuous operation.
Versatile Applications in Industrial Automation
Highly versatile, the PZ-G52N is ideal for diverse industrial automation tasks like presence detection, part positioning, and conveyor system control. Its PNP output type integrates smoothly with various control systems. The 2-m cable connection offers placement flexibility. Whether in manufacturing, packaging, or material handling, this sensor's precision and reliability boost operational efficiency, minimizing downtime and errors in industrial processes.
Technical Specifications
| Model | PZ-G52N |
|---|---|
| Type | Through-beam photoelectric sensor (high-power type) |
| Detection Distance | 40 m (131.2 ft) for standard alignment |
| Light Source | Infrared LED ×2 (invisible light) |
| Detectable Objects | Transparent and opaque materials (e.g., plastic, metal, glass) |
| Sensitivity Adjustment | 1-turn trimmer (230° rotation) |
| Response Time | ≤500 µs |
| Operation Mode | Light-on/Dark-on (switch-selectable) |
| Indicator Lamp | Power (T): Orange LED; Output (R): Orange LED; Stable operation: Green LED |
| Control Output | NPN open-collector, 30 V max., 100 mA max., residual voltage ≤1 V |
| Power Supply | 10-30 VDC ±10% (ripple ≤10%) |
| Current Consumption | Transmitter: ≤25 mA; Receiver: ≤28 mA |
| Enclosure Rating | IP67/IP69K (dustproof, waterproof up to 1 m immersion for 30 minutes) |
| Ambient Temperature | -20 to +55°C (-4 to 131°F) |
| Relative Humidity | 35-85% RH (non-condensing) |
| Ambient Light | Incandescent lamp: ≤5,000 lux; sunlight: ≤20,000 lux |
| Vibration Resistance | 10-55 Hz, 1.5 mm double amplitude (2 hours in X, Y, Z directions) |
| Shock Resistance | 1,000 m/s² (6 shocks in X, Y, Z directions) |
| Case Material | Glass-fiber reinforced PBT (housing), poly arylate (lens cover) |
| Weight | Approx. 60 g (cable type, including 2-m cable) |
| Certifications | CE, RoHS |
| Applications | Industrial automation, presence detection, part positioning, conveyor systems |
| Accessories | Instruction manual included |
