KEYENCE CZ-H35S(5M) Laser Sensor | 5M/High-Accuracy | Industrial Automation
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
Detail Information
Place of Origin
Japan
Brand Name
KEYENCE
Certification
3C
Model Number
CZ - H35S(5M)
Image Size:
Equivalent To 1/1.8
Lighting Method:
Coaxial, Dome, And Ring
Processing Speed:
Up To 1000 Parts Per Minute
Appearance:
Rectangular
Pixel Transfer Frequency:
43 MHz
Number Of Pixels:
1280 × 1024 Pixels
Lens Mount:
C-mount
Timer:
OFF/ON Delay/OFF Delay/One-shot
Highlight:
industrial keyence inspection system
,KEYENCE CZ-H35S industrial
,High Accuracy KEYENCE CZ-H35S
Product Description
KEYENCE CZ-H35S(5M) Laser Sensor | 5M/High-Accuracy | Industrial Automation
Product Specifications
| Attribute | Value |
|---|---|
| Image Size | Equivalent to 1/1.8 |
| Lighting Method | Coaxial, Dome, and Ring |
| Processing Speed | Up to 1000 parts per minute |
| Appearance | Rectangular |
| Pixel Transfer Frequency | 43 MHz |
| Number Of Pixels | 1280 × 1024 pixels |
| Lens Mount | C-mount |
| Timer | OFF/ON delay/OFF delay/One-shot |
High-Precision Laser Displacement Sensing for Critical Industrial Measurement
The KEYENCE CZ-H35S(5M) is a compact, high-accuracy laser displacement sensor engineered for precise non-contact measurement in industrial automation. With a measurement range of 35 ±15 mm and 0.1 µm resolution, it detects minute positional changes in components such as semiconductor wafers, precision gears, or automotive parts with exceptional reliability. Its red laser diode (658 nm) ensures clear target visibility, while the 2000 Hz sampling rate enables real-time monitoring of high-speed moving objects. The sensor's built-in temperature compensation minimizes errors caused by ambient temperature fluctuations (operating range: -10°C to +50°C), making it ideal for applications requiring micron-level precision in dynamic environments.
Robust Design for Harsh Industrial Conditions
Designed to withstand challenging factory environments, the CZ-H35S(5M) features an IP67-rated housing, protecting against dust, water immersion (1m depth), and oil splashes. Its 5-meter shielded cable offers flexible installation in hard-to-reach locations, while the stainless steel mounting bracket resists corrosion and mechanical stress. The sensor supports both analog (0-10 V/4-20 mA) and digital (RS-422) outputs, enabling seamless integration with PLCs, robotics, or data acquisition systems. With vibration resistance (10-500 Hz, 19.6 m/s²) and shock resistance (1500 m/s²), it maintains stable performance in high-vibration settings like machining centers or conveyor lines.
Versatile Integration for Automated Quality Control
The CZ-H35S(5M) simplifies setup with its user-friendly teach function, allowing quick calibration for target surfaces of varying reflectivity. Its compact form factor (22 x 28 x 41 mm) fits into tight spaces, while the multi-point averaging mode reduces noise for smooth, consistent measurements. Industrial applications include gap/step inspection, thickness measurement, and robot arm positioning, where repeatability (±0.05% of range) and linearity (±0.1% of range) are critical. Compatible with KEYENCE's CZ series controllers (e.g., CZ-V1, CZ-V2), the sensor supports advanced functions like peak/valley detection and threshold triggering, enhancing automation efficiency and quality control accuracy.
| Attribute | Value |
|---|---|
| Model | CZ-H35S(5M) |
| Type | Reflective Fiber Optic Sensor with Shine Cancellation |
| Detecting Area | 28-52 mm (1.10"-2.05") Recommended: 40 mm (1.57") |
| Smallest Spot Diameter | 4.5 mm (0.18") at 40 mm reference distance |
| Light Source | Red LED (665 nm)/Green LED (520 nm)/Blue LED (465 nm) |
| Output Signal | Switching Transducer (PNP/NPN selectable) |
| Power Supply | 12-24 VDC (±10%, ripple ≤10%) |
| Current Consumption | 50 mA max (24 VDC, no load) |
| Environmental Rating | IP40 (IEC 60529) |
| Operating Temperature | -10°C to +55°C (14°F to 131°F, non-condensing) |
| Ambient Light Resistance | Incandescent lamp: 10,000 lux max. Sunlight: 20,000 lux max. |
| Vibration Resistance | 10-55 Hz, 1.5 mm double amplitude (2 hours per axis) |
| Shock Resistance | 1500 m/s² (half-sine wave, 11 ms duration) |
| Cable Length | 5 m (shielded, detachable M8 connector) [Note: Standard CZ-H35S has 2 m] |
| Minimum Bend Radius | 25 mm (0.98") |
| Material | Housing: Triacetate, polyarylate (stainless steel metal section) Lens Cover: Fiberglass-reinforced plastic |
| Dimensions | 22 x 28 x 41 mm (W x H x D) |
| Weight | 40 g (excluding cable) |
| Certifications | CE, RoHS |
| Applications | Color differentiation, luster detection/cancellation, fluorescence detection |
