STÜBBE ZE 950 - Float-Position-Detect/Monostable-Signal-Switch - ABS Dovetail Mount Flow Limit Reed Switch
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
Detail Information
Place of Origin
Germany
Brand Name
STÜBBE
Certification
3C
Model Number
ZE 950
Product Model:
STÜBBE ZE 950
Product Type:
Industrial Limit Contact / Position Sensor
Detection Function:
Valve Position Monitoring
Application Type:
Open/Close Position Feedback
Sensor Technology:
Mechanical Limit Switch Contact
Signal Output:
Electrical Switching Signal
Installation Compatibility:
STÜBBE Valves And Actuators
Automation Interface:
PLC / DCS Control System Compatible
Product Description
STÜBBE ZE 950 - Float-Position-Detect/Monostable-Signal-Switch - ABS Dovetail Mount Flow Limit Reed Switch
Limit Reed Switch for DFM Float Flowmeters
The ZE 950 is a monostable (NO) limit reed switch clamped to the DFM 165 -350 float flowmeter dovetail. Key features include ABS housing, IP65 protection, 230V AC/DC operation, 0.5A / 10VA switching capacity, 1010 Ω resistance, 10 mm hysteresis, and operating temperature range of 0 to +55 °C. Includes DIN EN 175301-803 plug. Pairs with ZE 3060 (2-point) or ZE 3061 (contact protection relay). ZE 951 is the bistable variant.
Application & Features
Flow Limit Alarms on Plastic Piping
Clamps onto the flowmeter tube to trip at min/max/intermediate flow as the magnetic float passes. Drives pump interlocks, filter alarms, and batch cut-off in chemical/water plastic piping systems (compatible with Stubbe PP/PVDF valves). Features tool-free dovetail mounting for retrofit without shutdown. Always add ZE 3061 when switching power loads.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | ZE 950 |
| Product Type | Limit Reed Switch / Flow Signal Transmitter |
| Function | Monostable (Normally Open Contact) |
| Housing Material | ABS |
| Ambient Temperature | 0 - 55 °C |
| Connector | According to DIN EN 175301-803 |
| Voltage | 0 - 230 V AC/DC, 50/60 Hz |
| Switching Current | 0.5 A (max.) |
| Switching Capacity | 10 VA (max.) |
| Protection Class | IP 65 (with connector plug mounted) |
Packaging & Shipping
