Integral Conductivity/Resistivity System — Digital S³L Output, K=10.0 (High-Range)
The +GF+ Signet 3‑2850‑51‑84 is an integral-mount conductivity/resistivity system pairing 2850 sensor electronics with a 2842 electrode (K=10.0 cm⁻¹) for high-range ionic-strength measurement. Parameters: 4.6 m cable, 12–24 VDC, Digital (S³L) output, accuracy ±2% of reading, NEMA 4X/IP65, –10 to +85 °C, and EasyCal auto-recognition for field calibration.
Role in Automation — Where Used & Core Function
It delivers a stable, temperature-compensated conductivity signal into Signet 9900/8900 controllers or a PLC/DCS to enforce blowdown limits, concentrate monitoring, reject/reclaim logic, and discharge compliance alarms. Typical use: cooling-tower/boiler blowdown, brackish/brine loops, concentrate from RO/EDI, and high-TDS industrial effluent where low-range electrodes would saturate. The K=10.0 cell + S³L digital link prevents analog drift over long runs while keeping calibration audit-friendly.
Product Specifications: +GF+ Signet 3-2850-51-84
| Parameter Category | Specification Details |
|---|---|
| Model / Part No. | 3-2850-51-84 (GF Code: 159002159) [12†L14-L15] |
| Product Type | Integral Conductivity/Resistivity Sensor System [12†L14] |
| Output Signal | Digital (S³L) [7†L10][8†L16][9†L18][10†L6] |
| Compatible Instruments | Signet 8900, 9900, 9950 Transmitters [9†L19-L22][10†L21-L22] |
| Supply Voltage (Output) | 5 VDC ±5% (regulated, max. 3.0 mA) [8†L28-L29] |
| Process Connection | 3/4 inch MNPT (CPVC body) [6†L12-L13][12†L14-L15] |
| Thread Type | NPT (National Pipe Thread) [12†L14-L15] |
| Electrode Type | Stainless Steel (316L) [6†L16][6†L18] |
| Cell Constant (K) | 10.00 cm⁻¹ [6†L18][7†L14][12†L14-L15] |
| O-Ring Material | FPM (Viton) [6†L12] |
| Max. Operating Temp. | 85°C (185°F) [8†L34] |
| Enclosure Rating | NEMA 4X / IP65 [8†L33][9†L22-L23] |
