+GF+ 3-2100-1H - Valve-Control / Flow-Regulate - Leakproof Durable Industrial Diaphragm Valve
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
Leakproof Industrial Diaphragm Valve 3-2100-1H
,Flow-Regulate Industrial Diaphragm Valve 3-2100-1H
,Durable Industrial Diaphragm Valve 3-2100-1H
Small-Bore Turbine Flow Sensor for Clean-Liquid Automation (Model 3‑2100‑1H)
The +GF+ Signet 3‑2100‑1H is an inline turbine (rotor) flow sensor optimized for small-diameter process lines and clean liquids. Key parameters include a 3–38 L/min (0.8–10 GPM) range, PVDF wetted parts with ceramic bearings, FKM seals, and a 5–24 VDC powered open-collector pulse/frequency output on a shielded cable. Its removable NEMA 4X electronics let you service the sensor without disturbing piping.
Where It’s Used, What It Enables, and Why It’s Chosen
Installed on ¼–½” tubing or ½” pipe via union/barb/fusion/NPT options, it feeds a flow-proportional pulse signal into Signet instruments or a PLC counter for dosing proportionality, pump-protection interlocks, batch totalization, and flow alarms. Typical uses include chemical addition, fertigation, textile dyeing, high-purity chemical skids, and water/additive loops. Advantages are excellent chemical resistance, compact form factor, and field-serviceable electronics—keeping loops running without full teardown.
Product Specifications: GF Signet 3-2100-1H Turbine Flow Sensor
| Parameter | Specification |
|---|---|
| Product Type | Turbine Flow Sensor (PVDF Body) |
| Flow Range (High) | 3 – 38 lpm; 0.8 – 10 gpm |
| Linearity / Repeatability | ±3% of reading / ±0.5% of reading |
| Wetted Materials | PVDF body/rotor; Ceramic bearings; FKM O-rings |
| Output Signal | Open collector (sinking), max 30 mA |
| Power Supply | 5 – 24 VDC ±10%, regulated, max 1.5 mA |
| Pressure / Temp. Rating | 16 bar @ 20 °C (232 psi @ 68 °F) |
| Process Connection | Hose: DN8 (1/4”), DN10 (3/8”), DN15 (1/2”); Pipe: DN15 (1/2”) |
| Cable Length | 4.6 m (15 ft), extendable up to 300 m |
| Approvals / Compliance | CE, RoHS, China RoHS, FCC |
