+GF+ 3-2100-1H - Valve-Control / Flow-Regulate - Leakproof Durable Industrial Diaphragm Valve
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
Durable Industrial Diaphragm Valve
,Leakproof Industrial Diaphragm Valve
,Flow-Regulate Industrial Diaphragm Valve
High-Flow Turbine Flow Sensor for Small-Diameter Process Lines
The +GF+ Signet 3‑2100‑1H is a Type 2100 turbine (in-line rotor) flow sensor engineered for small-diameter piping where continuous, frequency-based flow measurement of clean liquids is required. Key parameters: 3–38 LPM (0.8–10 GPM) range, ±3% of reading linearity, ±0.5% repeatability, powered by 5–24 VDC with an open-collector NPN frequency output, and a 4.6 m shielded twisted-pair cable. Wetted materials are injection-molded PVDF body + ceramic bearings/shaft with FKM (Viton) O-rings for broad chemical resistance, and the removable electronics carry a NEMA 4X seal for field serviceability.
Where It's Deployed, Core Automation Function & Why It's Chosen
Its core function is to generate a flow-proportional frequency signal that feeds Signet instruments (8550 / 8900 / 9900 / 9950) or a PLC high-speed counter for dosing pump control, batch totalization, pump-protection interlocks, and flow-alarm logic. Typical uses include chemical additive skids, fertigation, textile dyeing, high-purity chemical dispensing, and water-treatment dosing loops—always clean liquid only (not gas). Advantages are the non-magnetic turbine + all-PVDF wetted path for aggressive media compatibility, union-end/barb/threaded connector flexibility for tubing or ½″ pipe, and field-replaceable NEMA 4X electronics that simplify maintenance without breaking the piping.
Product Specifications: GF Signet 3-2100-1H
| Parameter | Specification |
|---|---|
| Product Type | Turbine Flow Sensor |
| Flow Range | High: 3 – 38 lpm (0.8 – 10 gpm) |
| Accuracy / Repeatability | ±3% of reading / ±0.5% of reading |
| Wetted Materials | Body/Rotor: PVDF; Shaft/Bearings: Ceramic; O-rings: FKM |
| Output Signal | Open collector, sinking, max 30 mA |
| Power Supply | 5 to 24 VDC ±10%, regulated, 1.5 mA max, reverse polarity protected |
| Process Connection | Pipe: DN15 (1/2"); Hose: DN8 (1/4"), DN10 (3/8"), DN15 (1/2") |
| Max. Pressure / Temp | 16 bar (232 psi) @ 20°C (68°F); 9.3 bar (130 psi) @ 70°C (158°F) |
| Cable | 4.6 m (15 ft) PVC-jacketed, 2-conductor twisted pair with shield, 22 AWG |
| Housing Material | PBT / EVA (NEMA 4X) |
| Weight | 151 g (0.33 lbs) |
| K-Factors | 1/2" Pipe: 1725 pulses/US gal, 456 pulses/L 1/2" Hose: 1700 pulses/US gal, 449 pulses/L |
| Compliance | CE, FCC, China RoHS, RoHS |
