1. Product Overview
The Schmersal ZQ 700-02 is a high-security electromechanical safety switch engineered for critical guard door monitoring in industrial automation. Featuring a robust zinc die-cast housing (IP67 rated), this device utilizes a dual-channel coded cam actuator to prevent defeat attempts while monitoring hinged/sliding guards. Certified to ISO 13849-1 PL e (Category 4) and IEC 62061 SIL 3, it employs force-guided positively driven contacts that guarantee safe-state switching during component failures. The "02" suffix denotes dual-channel monitoring capability with integrated diagnostics. Designed for harsh environments (-25°C to +70°C), its corrosion-resistant construction withstands oils, coolants, and mechanical impacts. Integrated LEDs provide visual status for guard position, diagnostics, and power status, while the unique key-coded actuator system ensures only authorized access.
2. Key Technical Parameters
- Safety Ratings:
- PL e (ISO 13849-1 Cat. 4)
- SIL 3 (IEC 62061, PFHD: 3.5×10⁻⁹/h)
- Diagnostic Coverage: 99%
- Electrical:
- Voltage: 24V DC ±10%
- Contacts: 2 NC + 2 NO (force-guided)
- Current: 6A @ 250V AC / 8A @ 24V DC
- Mechanical:
- Actuator: Coded cam (6-pin security)
- Switching Angle: 15° ±2°
- Operating Force: 15N max
- Environmental:
- IP67 (IEC 60529)
- Shock Resistance: 100g (IEC 60068-2-27)
- Chemical Resistance: Resists oils, coolants, UV
- Diagnostics:
- Dual-color LEDs (green/red)
- Auxiliary fault contact
- Certifications:
- UL 508, CSA C22.2 No. 14
- ATEX Zone 22
3. Primary Applications
This switch is essential for safeguarding hazardous machinery:
- Robotic Workcells: Access door monitoring for collaborative robots
- Press Brakes: Safety gate position verification
- Plastic Injection Molding: Mold area access security
- Automotive Assembly Lines: Guarding robotic welding stations
- CNC Machining Centers: Tool changer access control
- Packaging Machinery: Hatch monitoring on vertical form-fill-seal machines
- Material Handling: Conveyor system guard position confirmation
- Heavy Equipment: Maintenance hatch security
Its coded actuator prevents defeat with standard keys, while IP67 protection ensures reliability in environments with dust exposure or liquid splashes.
4. Functional Advantages
- Tamper Resistance:
- 1,000+ unique key codes prevent unauthorized access
- Shielded design defeats magnetic bypass attempts
- Diagnostic Intelligence:
- Green LED: Guard closed/secure
- Red LED: Fault or guard open
- Auxiliary contact for PLC diagnostics
- Safety Assurance:
- Positively driven contacts (EN 50205 certified)
- Cross-monitored channels detect welding faults
- Durability:
- Zinc housing with chromate plating
- Stainless steel actuator components
- Installation Flexibility:
- ±2° angular tolerance
- Left/right hinged door compatibility
- Maintenance Optimization:
- Tool-free contact block replacement
1 million mechanical operations
- Compliance Ready:
- Pre-validated for EN ISO 14119
- SIL 3 integration capability
5. Safety Operation & Architecture
Interlock Sequence:
- Guard Closure:
- Coded cam engages switch mechanism
- NC contacts close within 25ms
- Continuous Monitoring:
- Dual processors compare contact states
- Timing discrepancies >5ms trigger shutdown
- Fault Response:
- Contact welding forces NO contact open
- Red LED illuminates during faults
- Reset Protocol:
- Manual key-turn required after guard closure
- System validates contact separation
Safety Architecture:
| Component | Safety Function |
|---|---|
| Dual processors | Cross-monitoring of contact states |
| Force-guided contacts | Guaranteed >0.5mm separation gap |
| Mechanical coding | Prevents actuator substitution |
| Auxiliary contact | Signals internal faults to PLC |
| Parameter/Attribute | Specification/Description |
|---|---|
| Product Type | Magnetic-Coded Safety Interlock Switch (Guard Locking Device) |
| Model Number | ZQ 700-02 |
| Safety Standards | ISO 13849-1, IEC 62061, IEC 60947-5-1, EN 1088 |
| Safety Level | PL d (ISO 13849-1), SIL 2 (IEC 62061), Category 3 |
| IP Rating | IP67 (Head & Body) / IP65 (Actuator) |
| Electrical Rating | Max. Load: • 6A @ 250V AC • 6A @ 24V DC |
| Contact Configuration | 2 NC (Normally Closed) + 2 NO (Normally Open) (Monitored safety outputs + auxiliary) |
| Operating Principle | RFID-Coded Magnetic Actuation (Prevents tampering/defeat) |
| Locking Force | 1,500 N (Static holding force) |
| Release Mechanism | Electrical Unlocking (12-24V DC, 0.5A) + Manual Emergency Release |
| Operating Distance | ≤15 mm (Max. gap between actuator and head) |
| Mechanical Life | ≥ 1,000,000 cycles (no load) |
| Electrical Life | ≥ 100,000 cycles (rated load) |
| Housing Material | Head: Fiberglass-reinforced polyamide Actuator: Stainless steel (AISI 304) |
| Ambient Temperature | -30°C to +70°C (Operation) / -40°C to +85°C (Storage) |
| Voltage Range | 24V DC ±10% (Control voltage for locking/unlocking) |
| Connection Type | M12 × 1, 8-pin connector (Coded per IEC 61076-2-104) |
| Response Time | <100 ms (Lock release upon signal) |
| Coding Security | 64-bit RFID (Prevents cross-actuation with other switches) |
| Mounting | Surface mount with M5 screws (Reinforced metal inserts) |
| Shock/Vibration | Shock: 30g (11ms) Vibration: 10–55 Hz, 0.35mm amplitude |
| Approvals | CE, UL Listed, cULus, TÜV |
| Typical Applications | Machine guards, safety doors, automated production cells requiring guarded access |
