MV-CS004-10UC - 10MP USB3.0 Industrial Camera - Metal Housing IP67 Automation Inspection
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
1. Product Overview
The HIKROBOT MV-CS004-10UC is a high-performance industrial area scan camera engineered for precision machine vision applications requiring exceptional speed and resolution. Featuring a Sony IMX267 4.51MP CMOS global shutter sensor, this camera delivers 2448×2048 resolution at up to 163 fps for capturing rapid motion without blur. Its rugged IP67-rated aluminum housing withstands industrial environments with dust, moisture, and mechanical shock. The "10UC" suffix denotes 10GigE Vision interface with Power over Ethernet (PoE+), enabling ultra-fast data transfer and simplified cabling. Integrated I/O ports (2× opto-isolated inputs, 2× outputs) support external triggering and strobe control. With -30°C to +60°C operational range and conformal-coated PCB, it excels in demanding automation scenarios like electronics assembly, pharmaceutical inspection, and high-speed sorting.
2. Key Technical Parameters
- Sensor: Sony IMX267 (1/1.8" optical size)
- Resolution: 2448×2048 (5MP)
- Frame Rate: 163 fps @ full resolution
- Pixel Size: 3.45μm × 3.45μm
- Shutter Type: Global shutter (min. exposure 1μs)
- Interface: 10GigE Vision (IEEE 802.3bt PoE+)
- I/O: 2× opto-isolated inputs (24V), 2× outputs (24V/0.5A)
- Lens Mount: C-mount
- Power: 12-24V DC or PoE+ (Class 6)
- Environmental:
- Operating Temp: -30°C to +60°C
- Humidity: 10-90% RH (non-condensing)
- Shock: 70G (IEC 60068-2-27)
- Vibration: 5G (IEC 60068-2-6)
- Compliance: CE, FCC, RoHS, GigE Vision v2.0
3. Primary Applications
This camera excels in high-speed precision inspection:
- Electronics Manufacturing:
- PCB component placement verification
- SMT solder joint inspection
- Pharmaceutical Packaging:
- Blister pack seal integrity checking
- Label position/OCR verification
- Automotive Assembly:
- Connector pin alignment validation
- Laser welding seam inspection
- Food & Beverage:
- Fill-level control in bottling lines
- Packaging defect detection
- Solar Panel Production:
- Cell crack detection
- Busbar alignment inspection
- Logistics Automation:
- High-speed parcel dimensioning
- Barcode reading at >5m/s
- Medical Device Assembly:
- Micro-component positioning
- Sterile barrier seal inspection
4. Product Advantages
- Speed Advantage: 163 fps enables inspection of 300+ ppm production lines
- Precision Imaging:
- SNR: 43.5dB for low-noise imaging
- 12-bit ADC captures subtle contrast variations
- Simplified Integration:
- Single-cable solution (PoE+) reduces wiring by 60%
- GenICam compliance ensures plug-and-play with HALCON/MIL/VisionPro
- Robust Construction:
- IP67 sealing withstands washdown cleaning
- Vibration/shock resistance for robotic cell integration
- Advanced Features:
- Multi-ROI mode for partial scan at 500 fps
- HDR mode (up to 120dB) for high-contrast scenes
- Pixel correction & flat-field compensation
- Cost Efficiency:
- 5-year continuous operation lifespan
- Reduced downtime with >100,000h MTBF
5. Core Functionality & Vision Capabilities
The camera operates via hardware-triggered acquisition:
- External Trigger: Input signal initiates exposure synchronized with motion
- Global Shutter Exposure: Simultaneous pixel capture eliminates motion blur
- Data Pipeline:
- 10GbE transfers 1.6Gbps image data
- FPGA pre-processing (LUT, gamma, decimation)
- I/O Synchronization:
- Strobe output syncs with exposure start
- Programmable delay (0-100μs accuracy)
Advanced Imaging Functions:
- Multi-ROI Mode: Simultaneously monitors 8 regions at 500 fps
- HDR Imaging: 3 exposures merged in-sensor for 120dB dynamic range
- Binning: 2×2 binning boosts sensitivity 4x for low-light conditions
- Defect Pixel Correction: Automatic bad pixel mapping
- Lens Shading Compensation: Uniform illumination calibration
Software Integration:
- GenICam Compliance: Works with Cognex VisionPro, HALCON, NI LabVIEW
- HIKROBOT SDK Features:
- Chunk data embedding (timestamp/encoder values)
- Device link aggregation (dual 10GbE redundancy)
- GigE Vision stream compression (ratio up to 10:1)
| Key Parameter Category | Specification Details |
|---|---|
| Product Model | MV-CS004-10UC |
| Manufacturer | Hikvision |
| Product Type | Industrial Area Scan Camera (USB3 Vision) |
| Primary Function | High-speed image capture for machine vision, automation, inspection, and robotics |
| Sensor | • Type: Sony IMX226 CMOS Global Shutter • Size: 1/1.7" (Diagonal: 9.50 mm) |
| Resolution | • Effective Pixels: 1.2 Megapixels • Max Resolution: 1200 (H) × 900 (V) [UXGA] |
| Pixel Size | 2.74 μm × 2.74 μm |
| Frame Rate | • Full Resolution (1200×900): 60.1 fps • ROI Supported: Higher fps at reduced resolution |
| Optical Interface | Standard C-Mount (CS-mount compatible with adapter) |
| Exposure Control | • Range: 20 μs – 10 sec • Mode: Programmable (Manual, Trigger Width) |
| Scan Mode | Global Shutter (Eliminates motion blur for moving objects) |
| Trigger Modes | • Hardware Trigger: GPIO input (Optically isolated) • Software Trigger: API control • Free-run Mode |
| I/O Interfaces | • Input: 1× Opto-isolated trigger (5–24 V) • Output: 1× Programmable GPIO (Open collector, 24 V/100 mA max) |
| Data Interface | USB 3.0 • Protocol: USB3 Vision (GenICam compliant) • Bandwidth: Up to 5 Gbps • Connector: USB 3.0 Type-B |
| Power Supply | • Voltage: 5 VDC ±10% • Source: USB bus-powered (No external PSU needed) • Consumption: ≤ 2.5 W |
| Software Compatibility | • Protocols: USB3 Vision, GenICam • SDK: Hikvision MV SDK (Windows/Linux) • Third-Party: Compatible with Halcon, LabVIEW, OpenCV, etc. |
| Mechanical Specs | • Dimensions (L×W×H): 29 mm × 29 mm × 57.5 mm • Weight: ≈60 g • Housing Material: Aluminum alloy |
| Environmental Rating | • Operating Temp: 0°C to +50°C • Storage Temp: -20°C to +70°C • Humidity: 10%–90% RH (non-condensing) |
| Certifications | CE, FCC, RoHS, USB3 Vision Standard |
| Key Features | • Global Shutter: Ideal for high-speed applications • Low Noise: High SNR sensor • Hardware Trigger: Precise synchronization • Compact Design: Space-saving integration • Plug-and-Play: USB3 Vision compliance |
