751105 - 2-Channel SIL3 PL e Safety Relay - Industrial Automation Compact High-Speed
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
safety others
,safety electronic circuit breaker
,industrial others
| Attribute | Value |
|---|---|
| Output Type | PNP/NPN |
| Light Source | LED |
| Mounting Type | Through-hole mounting |
| Detection Mode | Diffuse mode |
| Detection Principle | Optoelectronic |
| Protection Rating | IP67 |
| Housing Material | Stainless steel |
| Response Time | Less than 10 ms |
The Pilz 751105 PNOZ X3.1P is a flexible miniaturized safety relay designed for safeguarding applications requiring SILCL 3 / PL e (ISO 13849-1) performance. Featuring a 22.5mm width DIN-rail housing with pluggable spring-clamp terminals, it integrates 3 independent safety channels with semiconductor outputs for monitoring emergency stops, light curtains, or safety gates.
- Safety Ratings: SIL 3 (IEC 62061) / PL e Cat.4 (ISO 13849-1)
- Max. Safety Current: 6A per channel (AC-15: 250VAC / DC-13: 24VDC)
- Operating Voltage: 24VDC (10.2-30V) with reverse polarity protection
- Response Time: <100ms (all channels)
- MTTFd: 175 years (EN ISO 13849-1 calculation)
- Diagnostic Coverage (DCavg): >99%
- Connection: Plug-in spring-clamp terminals (2.5mm² cross-section)
- Ambient Temperature: -25°C to +60°C
- Mechanical Life: >10 million operations
- Standards: EN 60204-1, UL 508, IEC 62061
- Press Brakes: Two-hand control monitoring (ISO 16092 Stage III)
- Robotics: Collaborative cell emergency stops (ISO 10218-2)
- Conveyors: Belt alignment interlocking and zero-speed monitoring
- Packaging Machines: Rotary knife guard locking (ANSI B65.1)
- Plastic Injection: Mold protection barrier monitoring
- Automated Assembly: Light curtain muting/blanking circuits
Ideal for upgrading legacy systems due to single-unit functionality requiring no expansion modules.
- Ultra-Compact Footprint: 55% smaller than standard relays while delivering Cat.4 safety
- Auto-Diagnostics: Continuous monitoring of contact welding/circuit faults
- Universal Voltage Tolerance: Operates down to 10.2VDC for brownout resilience
- Cross-Circuit Detection: Identifies wiring shorts between channels
- Plug-and-Play Function Blocks: Time-delay options without external timers
- Cost Efficiency: Replaces 3+ conventional relays in control cabinets
Features internal replaceable fuses (500mA) and meets ISO 13855 response timing standards.
- Forcibly Guided Contacts: Mechanically linked relays prevent unsafe states (EN 60947-5-1)
- Configurable Timing: 0.1s-600s time delays via rotary switches for startup/restart interlocks
- External Device Monitoring (EDM): Detects stuck outputs in linked controllers
- Auto-Reset / Manual Reset Options: Selectable via DIP switches
- Short-Circuit Protection: All outputs secured with PTC thermistors
- Status Feedback: Auxiliary N/C contact for PLC signaling
- Overvoltage Shielding: Built-in 39V surge suppression
Includes manual operation button for contact testing and lockable terminal covers (DIN EN 62444).
| Product Type | Configurable Electronic Safety Controller (Base Unit) |
| Order Number | 751105 |
| Safety Standards Compliance | EN ISO 13849-1, EN IEC 62061, EN 61010-1 |
| Supply Voltage | 24 V DC (20.4-28.8 V DC) |
| Power Consumption | 1.5 A (max, including connected modules) |
| Protection Rating | IP20 (EN 60529) |
| Housing Material | Polycarbonate (UL94 V-0) |
| Dimensions | 45 mm × 126 mm × 129 mm |
