MTS RPS1750MD70AS2G1100 - 1750mm IP67 Non-Contact - Industrial Stainless - High-Accuracy Position Sensor
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
ip67 MTS RPS1750MD70AS2G1100
,ip67 electronic circuit breaker
,industrial MTS RPS1750MD70AS2G1100
| Attribute | Value |
|---|---|
| Battery Life | 10 hours |
| Connectivity | Wireless |
| Model | MTS-100 |
| Special Features | Noise cancellation |
| Compatibility | Universal |
| Color | Black |
| Material | Plastic |
| Size | Medium |
The MTS RPS1750MD70AS2G1100 is a precision magnetostrictive linear position transducer engineered for extreme industrial environments. Designed with Temposonics® A-Series technology, it delivers non-contact absolute position measurement over a 1750mm (1.75m) stroke with ±0.05% FS accuracy. Its seamless 316L stainless-steel housing (IP67/IP69K-rated) withstands pressures up to 300 bar, aggressive coolants, and 100g mechanical shocks. Featuring both analog and digital outputs, the sensor enables real-time position feedback for hydraulic cylinders, presses, and mobile machinery while supporting SIL 2/PLe functional safety. IO-Link integration (G1100 suffix) facilitates plug-and-play Industry 4.0 connectivity.
- Measuring Range: 0-1750 mm (±875mm bidirectional)
- Accuracy: ≤±0.05% full scale (FS) at 23°C
- Resolution: 0.01 mm (14-bit digital)
- Outputs: Analog (4-20mA/0-10V) + IO-Link V1.1 (COM3)
- Linearity: <±0.01% FS (post-calibration)
- Response Time: <0.5 ms
- Pressure Rating: 300 bar static, 200 bar dynamic
- Housing: 316L SS (corrosion-resistant) with PEEK seals
- Temperature Range: -40°C to +125°C (process) / -40°C to +85°C (electronics)
- EMC: EN 61000-6-4 certified (200V/m RF immunity)
- Connection: 5-pin M12 connector (A-coded)
- Vibration/Shock: 20g (10-2000 Hz) / 100g (6 ms)
- Hydraulic Presses: Monitors die height in 15,000-ton forging presses
- Steel Mills: Tracks continuous casting oscillator stroke under 1500°C radiant heat
- Offshore Cranes: Measures boom extension in Zone 2 marine environments
- Energy: Valve positioning in turbine control systems (100+ bar steam)
- Mobile Equipment: Load sensing in Tier 4 excavator implements
- Test Rigs: High-frequency (1kHz+) fatigue testing with sub-millimeter repeatability
- Zero Contact Wear: Magnetostrictive waveguide lasts >250 million cycles
- Absolute Positioning: Retains position after power loss (no homing)
- Multi-Layer Diagnostics: Self-monitors signal integrity, temperature drift, and voltage anomalies
- Overload Protection: 150% stroke overtravel tolerance
- Smart Connectivity: IO-Link enables remote configuration and predictive maintenance
- Drift-Free Operation: ±0.002% FS/°C thermal stability via ASIC compensation
Reduces calibration costs by 90% while improving system uptime through predictive diagnostics.
- Programmable Alarms: Set digital thresholds for position limits via IO-Link
- Dynamic Update Rates: Configurable sampling from 1Hz to 1kHz
- Condition Monitoring: Tracks vibration spectra (>5kHz) for bearing wear detection
- Data Encryption: Secure OUC communication via IO-Link Safety (IEC 61784-3-18)
- Redundancy Support: Dual-output versions available for safety loops
- Auto-Calibration: Teach-in function aligns zero/max points in <10 seconds
Integrates with PLCs (Siemens TIA Portal, Rockwell Studio 5000) via MTS Temposonics® EDGE software.
| Detailed Specifications | |
|---|---|
| Model Identification | RPS1750MD70AS2G1100 |
| Product Line | Temposonics® RPS (Industrial Non-Contact Position Sensor) |
| Sensing Length (Stroke) | 1750 mm (68.9 inches) |
| Sensor Body Material | Anodized Aluminum (EN AW-6063 T6) |
| Sensor Rod Material | Stainless Steel 1.4305/AISI 303 |
| Protection Rating | IP67 (NEMA 6 equivalent) |
| Maximum Bending Load | 15 N (at rod end) |
| Supply Voltage | +15 to +30 VDC (Nominal 24 VDC ±10%) |
| Power Consumption | ≤ 1.8 W (Typical at 24 VDC) |
| Primary Output 1 | 4-20 mA Analog Current (Fault: ≤ 3.6 mA / ≥ 21 mA) |
| Primary Output 2 | 0-10 V Analog Voltage (Fault: ≤ 0.5 V / ≥ 10.5 V) |
| Output Load Limits | ≤ 500 Ω (Current); ≥ 10 kΩ (Voltage) |
| Diagnostics | LED Status Indicator + Programmable Fault Signals |
| Linearity Error | ±0.025% Full Scale (FS) |
| Repeatability | ≤ 0.002% FS |
| Resolution | ≤ 5 µm |
| Response Time | ≤ 1.0 ms |
| Update Rate | 1 kHz |
| Temperature Coefficient | ±0.01% FS/°C (Gain); ±0.005% FS/°C (Offset) |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Storage Temperature | -40°C to +100°C (-40°F to +212°F) |
| Vibration Resistance | 20 g (10-2000 Hz per IEC 60068-2-6) |
| Shock Resistance | 100 g / 11 ms (IEC 60068-2-27) |
| Magnet Type | External Float Magnet (Included, PPS Encapsulated) |
| Max. Operating Gap | 25 mm (from rod centerline) |
| Max. Target Speed | 10 m/s |
| Mounting Options | Threaded Ends (M8x1), Flange Mount |
| Electrical Interface | 5-pin M12 × 1 A-coded Male Connector |
| Cable Length | 3 m (PUR Shielded Cable, indicated by "S2") |
| EMC Compliance | EN 61000-6-2 (Immunity), EN 61000-6-4 (Emissions) |
| Hazardous Area Certification | ATEX/IECEx: Ex ia IIC T6 Ga / Ex ia IIIC Da (Zone 0/20) - "G1100" suffix |
| Functional Safety | SIL 2 (IEC 61508) capable with redundant configuration |
| Teach-in Capability | Programmable measurement range via push-button or IO-Link |
| Diagnostics | Magnet detection, signal integrity monitoring, over-temperature protection |
| Media Compatibility | Resistant to oils, coolants, and mild chemicals (avoid strong solvents) |
| Primary Use Cases | Tank level sensing, material handling, press automation, renewable energy systems |
| Industry Suitability | Chemical, Oil & Gas, Food & Beverage (Hazardous area compliant) |
| MTBF (Mean Time Between Failures) | > 50 years (per IEC 61709) |
Xiamen ZhiCheng Automation Technology Co., Ltd is a leading global supplier of control system components. We specialize in control systems and drives.
With many years of experience in the industrial sector, we consistently deliver the highest quality of spare parts which make sure that all jobs are perfectly completed.
We specialize in PLC, Sensors, HIM, and Transmitters.
Best Supply Brands As Following: Bently nevada, +GF+, Rosemount, ABB, Allen-Bradley, Foxobro. Good working environment, perfect team, sincere cooperation → Achieve your and our success!
