BL20-S4T-SBCS - IP67 4-Port Ethernet - Industrial Automation Stainless - Fieldbus Node
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
ip67 BL20-S4T-SBCS
,ip67 electronic circuit breaker
,industrial BL20-S4T-SBCS
| Attribute | Value |
|---|---|
| Type | I/O System |
| Communication Protocol | Ethernet/IP |
| Number Of I/O Modules | up to 64 |
| Mounting Type | DIN rail |
| Output Voltage | 24 VDC |
| Power Supply | 24 VDC |
| Model | BL20 |
| Protection Rating | IP20 |
The Turck BL20-S4T-SBCS is a modular I/O interface system designed for robust data acquisition and signal conditioning in industrial automation environments. Part of Turck's BL20 series, this device integrates seamlessly into distributed control architectures, supporting communication via EtherNet/IP, PROFINET, or Modbus TCP protocols. Its compact, fieldbus-independent design enables flexible deployment in machinery, process control, and logistics systems. The BL20-S4T-SBCS features a rugged aluminum housing with IP67/IP69K protection, ensuring resistance to dust, moisture, oils, and mechanical vibrations.
Engineered for versatility, the module supports 4 digital inputs (PNP/NPN) and 4 transistor outputs, making it ideal for connecting sensors, actuators, and PLCs in harsh environments. Compliance with UL 61010, CE, and RoHS standards guarantees global safety and reliability.
- Input Channels: 4x digital (10-30 V DC, PNP/NPN configurable)
- Output Channels: 4x transistor (0.5 A per channel, 30 V DC)
- Communication Protocols: EtherNet/IP, PROFINET, Modbus TCP (via SBC interface)
- Operating Voltage: 24 V DC (±10%), typical for industrial systems
- Temperature Range: -25°C to +70°C (operational), -40°C to +85°C (storage)
- Protection Class: IP67/IP69K for harsh environments
- Housing Material: Aluminum with corrosion-resistant coating
- Certifications: UL, CE, RoHS, and IEC 61131-2 compliance
These parameters ensure reliable performance in high-noise and high-vibration applications.
The BL20-S4T-SBCS is critical in industries requiring decentralized I/O solutions:
- Automotive Manufacturing: Connects photoelectric sensors and actuators in robotic welding/painting systems
- Packaging Machinery: Interfaces with fill-level sensors and barcode scanners for automated packaging lines
- Process Control: Monitors valves, pumps, and temperature sensors in chemical/pharmaceutical plants
- Material Handling: Integrates with conveyor belt sensors and sorting systems in logistics hubs
- Food & Beverage: Withstands washdown environments for hygiene-critical production zones
Its modularity also suits renewable energy systems, water treatment plants, and mobile equipment.
| Parameter | Value/Description |
|---|---|
| Product Category | Modular I/O System (Fieldbus Coupler for Safety Applications) |
| Model Number | BL20-S4T-SBCS |
| Bus Protocol | PROFIsafe over PROFIBUS DP (DPV1) |
| Safety Integrity Level | SIL 3 (IEC 61508), PL e (ISO 13849-1) |
| Input/Output Channels | Configurable via modular I/O expansion (e.g., digital/analog signals) |
| Power Supply | 24 V DC (19.2-28.8 V DC) |
| Power Consumption | ≤ 5 W (base module) |
| Operating Temperature | -25°C to +60°C (-13°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Protection Rating | IP20 (module), IP67 for field connections (with appropriate housing) |
| Housing Material | Polycarbonate (flame-retardant, UL94 V-0) |
| Connection Type | Screw terminals or M12 connectors (field side) |
| Communication Speed | Up to 12 Mbps (PROFIBUS DP) |
| Diagnostics | LED indicators for power, bus status, and module errors |
| Certifications | CE, UL, cULus, ATEX (Zone 2/22), IECEx, SIL 3, PL e |
| EMC Compliance | EN 61000-6-2 (Immunity), EN 61000-6-4 (Emissions) |
| Mounting | DIN Rail (EN 60715) |
| Dimensions (W x H x D) | 38 mm x 126 mm x 117 mm (1.5" x 4.96" x 4.61") |
| Weight | Approx. 350 g (0.77 lbs) |
| Redundancy Support | Optional redundancy modules for fail-safe operation |
| Hot-Swapping | Supports module replacement without powering down the system |
| Safety Functions | Cross-circuit monitoring, short-circuit detection, and fault diagnostics |
