Multi-Hazard Armor, Instant-Clamp Dynamic Base | MTL-5032 Sentinel
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 100*100*100mm |
| Delivery Period: | 3 day |
| Payment Method: | T/T |
| Supply Capacity: | 1piece in stock |
industrial MTL-5032
,High Precision MTL-5032
,industrial MTL 5032 module
| Attribute | Value |
|---|---|
| Keyword | MTL4544 |
| Storage Temperature | -10-60°C |
| Beam Divergence | 1.2mrad |
| Quantity | 100% Original and Genuine |
| Model | MTL-100 |
| Number Of Channels | One |
| Dimensions | 200mm x 150mm x 100mm |
| Operating Temperature | 10-35°C |
The MTL 5032 is a compact, single-channel pulse isolator designed to provide galvanic isolation and signal conditioning for pulse, voltage, or current inputs in Zone 0/IIC hazardous environments. This device excels in transmitting high-frequency pulses (up to 50 kHz) with ±0.1% accuracy and a rapid response time of <250 µs, ensuring precise data transfer for applications such as flowmeters, proximity sensors, or turbine meters in oil refineries or chemical plants.
- Intrinsic safety parameters (Uo = 28 V, Io = 93 mA, Po = 0.65 W)
- Compliance with ATEX (II 1 GD Ex ia IIC T4-T6) and IECEx (Ex ia IIC -20°C ≤ Ta ≤ +60°C) certifications
- Wide input voltage range (20-35 VDC) with low power consumption (1.4 W)
- DIN rail mount design with plug-and-play terminals
- Reduces panel space by 30% compared to multi-channel alternatives
Built to withstand harsh environments, the MTL 5032 features a robust housing that operates reliably in temperatures ranging from -20°C to +60°C and humidity levels up to 95% RH non-condensing. The device weighs just 110 grams and measures 104 x 16 x 110 mm, offering a lightweight yet durable solution.
- Green LED indicator for real-time power status monitoring
- Failsafe mechanism maintains signal continuity during power fluctuations
- Integrated surge suppression and line fault detection
- 10-year operational lifespan with IEC 61508 functional safety compliance
| Specification | Detail |
|---|---|
| Model | MTL 5032 |
| Type | Single-channel intrinsic safety pulse isolator |
| Applications | Oil & gas refineries, chemical processing plants, pharmaceutical facilities |
| Signal Type | Pulse (up to 50 kHz), voltage, or current inputs |
| Isolation | 250 V AC between input, output, and power terminals |
| Accuracy | ±0.1% of signal span |
| Response Time | <250 µs to settle within 10% of final value |
| Dimensions | 104 x 16 x 110 mm (4.09" x 0.63" x 4.33") |
| Weight | 110 g (product weight) |
| Mounting | 35 mm DIN rail (EN 50022) |
