SRB-E-232ST - Emergency Stop Dual-Contact Relay - SS IP65 SIL2 Industrial Safety
| MOQ: | 1 |
| Price: | USD 100-10000/Piece |
| Standard Packaging: | 50*50*50mm |
| Delivery Period: | 3-7 |
| Payment Method: | T/T |
| Supply Capacity: | 1/piece in stock |
1. Product Overview
The Schmersal SRB-E-232ST is a high-performance safety relay engineered for dual-circuit monitoring in critical industrial automation systems. Featuring a stainless steel housing (IP67 rated), this DIN-rail mountable module provides ISO 13849-1 PL e (Category 4) and IEC 62061 SIL 3 compliant safety control for E-stops, guard doors, and safety sensors. Its dual-channel architecture independently monitors two separate safety circuits with force-guided contacts and integrated diagnostics. Operating at 24V DC within -25°C to +60°C, the relay withstands harsh industrial environments including exposure to oils, coolants, and mechanical vibrations. The integrated TFT diagnostic display provides real-time status visualization, while SIL 3 certification ensures fault-tolerant operation in automotive, robotics, and heavy machinery applications.
2. Key Technical Parameters
- Safety Ratings:
- SIL 3 (IEC 62061, PFHD: 2.1×10⁻⁹/h)
- PL e (ISO 13849-1 Cat. 4, DCavg=99.2%)
- Electrical Specifications:
- Voltage: 24V DC ±10% (19.2–28.8V)
- Safety Outputs: 4× relay (5A @ 250V AC)
- Input Circuits: 2 independent dual-channel (S11/S12, S21/S22)
- Response Time: ≤100ms
- Mechanical:
- Dimensions: 45×105×121mm (W×H×D)
- DIN Rail Mounting: EN 60715 TH35
- Environmental:
- IP67 (NEMA 4X equivalent)
- Shock Resistance: 50g (IEC 60068-2-27)
- Diagnostics:
- 2.4" TFT color display
- USB interface for event logging
- Certifications:
- UL 508, CE, UKCA
- IECEx Ex ec IIIC T80°C Dc
3. Primary Applications
This relay is essential for safeguarding complex machinery:
- Automotive Stamping Presses: Coordinated E-stop monitoring across multi-press lines
- Robotic Welding Cells: Simultaneous safety gate and light curtain integration
- Pharmaceutical Packaging: Isolator door and gloveport monitoring in GMP environments
- Plastic Injection Molding: Hydraulic unit safety and mold guard interlocks
- Material Handling Systems: AGV safety circuit and charging station control
- Food Processing Lines: Hygienic guard monitoring with CIP washdown resistance
- CNC Machining Centers: Tool changer and chip conveyor safety
- Power Substations: High-voltage cabinet access control
Its dual-circuit design reduces wiring complexity while maintaining SIL 3 isolation between safety functions in high-risk environments.
4. Functional Advantages
- Advanced Diagnostics:
- Color TFT display shows real-time circuit status and fault histories
- Event logging with timestamp simulation (500+ entries)
- Space Optimization:
- 45mm width consolidates two safety circuits in single module
- Unified DIN rail mounting saves 60% panel space
- Safety Redundancy:
- Physically isolated circuits prevent fault propagation
- Force-guided contacts (EN 50205 certified)
- Configuration Flexibility:
- Independent reset modes per circuit (manual/auto)
- Configurable time delays (0.1–30s)
- Durability Features:
- Corrosion-resistant SS316 housing
100,000 mechanical operations
- Integration Efficiency:
- Plug-and-play M12 connectors (optional)
- Pre-certified templates for ISO 13850
- Cybersecurity:
- Password-protected configuration
- Secure firmware updates via USB
5. Safety Operation & Architecture
Dual-Circuit Monitoring Logic:
- Input Validation:
- Continuous cross-comparison of S11/S12 and S21/S22 signals
- Detects discrepancies >3ms (contact welding/line faults)
- Startup Self-Test:
- Validates contact separation (≥0.5mm) upon power-up
- Checks processor/RAM integrity
- Output Control:
- Safety relays (K1-K4) enable only when both circuits validate
- Semiconductor outputs signal diagnostics to PLC
- Fault Management:
- Forces affected circuit outputs open during faults
- TFT display shows fault codes with recommended actions
- Reset Protocols:
- Manual reset via front button or external key switch
- Auto-reset after non-critical warnings
Diagnostic Display Codes:
| Display Icon | Condition | Action Required |
|---|---|---|
| Green Check | Normal operation | None |
| Yellow Triangle | Input discrepancy | Inspect safety devices |
| Red Circle | Critical fault | Manual reset after repair |
| Blue Hourglass | Time-delay active | Wait for cycle completion |
| Parameter | Specification/Value |
|---|---|
| Product Type | Emergency Stop Switch (Twist Release) |
| Series | SRB-E Standard Series |
| Actuator Design | Ø 40 mm Mushroom Head Red (RAL 3000) with yellow base ring (ISO 13850 compliant) |
| Contact Configuration | 2 NC (Safety) + 1 NC/1 NO (Auxiliary) • Safety contacts: Terminals 13-14, 21-22 • Auxiliary: 31-32 (NC), 41-42 (NO) |
| Safety Integrity | Category 4 / PL e (EN ISO 13849-1) Stop Category 0 (IEC 60204-1) |
| Protection Rating | IP65 (Frontal ingress protection) IP54 (Housing rear) |
| Electrical Ratings | • Voltage: 24-240V AC/DC • Current: 10A (AC-15), 6A (DC-13) • Power: 3000 VA / 180 W |
| Mechanical Durability | ≥ 1,000,000 cycles (No load) |
| Electrical Durability | 100,000 cycles (At rated load) |
| Actuation Force | ≥ 80 N (Meets ISO 13850 minimum requirement) |
| Reset Mechanism | Key-operated Twist Release Anti-rotation collar prevents tampering |
| Housing Material | Glass-fiber reinforced PA 6.6 Halogen-free, UV-stabilized |
| Contact Material | AgNi (Silver Nickel) contacts Self-cleaning design |
| Terminal Connection | Screw Clamp Max. wire size: 2.5 mm² Torque: 0.5–0.6 Nm |
| Operating Environment | Temperature: -25°C to +70°C Humidity: ≤ 93% RH (non-condensing) |
| Impact Resistance | 50 J (IK08 protection per EN 62262) |
| Mounting | Panel Cutout: Ø 22.5 mm Depth: 70 mm |
| Safety Features | • Positive Opening (EN 60947-5-1) • Mechanically linked dual-channel safety circuit |
| Global Certifications | CE, UL 508, CSA C22.2 No.14, TÜV, EAC, CCC, KC |
| Compliance Standards | EN/IEC 60947-5-1, EN ISO 13850, EN 60204-1, ANSI B11.19 |
| Vibration Resistance | 10–55 Hz (Amplitude 0.35 mm) per EN 60068-2-6 |
